BLUE SEA – MRBF Terminal Fuse Block for Single Fuse / BS-5191

Description BLUE SEA – MRBF Terminal Fuse Block for Single Fuse / BS-5191 HIGHLIGHTS Compact, high-amp fuse—appropriate for DC Main, inverter, windlass, and bow thruster circuit protection. Provides high current protection in tight space constraints. Ignition protected when used with Blue Sea Systems’ MRBF Terminal Fuse. Isolated stud design uses standard M8 hardware and permits stacking of terminals. Insulating cap prevents accidental shorts. Accepts 5∕16″ ring terminals. Mounts on 3/8” terminal studs. Fuse sold separately. SPECIFICATIONS PART NUMBER: BS-5191 IGNITION PROTECTED: NO MAXIMUM AMPERAGE: 300A MAXIMUM VOLTAGE: 58V DC TERMINAL STUD: M8 (5/16″) MAXIMUM TORQUE:75 in-lb (8.47 Nm) WEIGHT 0.07 kg (0.16 lb) OVERALL DIMENSIONS (LENGTH x WIDTH x HEIGHT): 67mm x 146mm x 44mm
